K87-M2381-000 飞达气缸 CL24MM飞达气缸
产品编号:00455

产品规格: K87-M2381-000

产品类别:YAMAHA机器配件

产品备注:YAMAHA飞达配件

4M8]G@QV8D00`~)]$RN$5VR
CL24气缸

CL24气缸 1

CL24气缸 2


9I]CT}N7$0CK[(JW]U2_AAY

K87-M2381-000 飞达配件



PBSA16x30 飞达气缸 CL款24MM飞达配件



KW1-M451G-000 LEVER ASSY 1 AS -A24-1145
KW1-M458A-000 SET PLATE ASSY 1 AS -A24-1167
KW1-M458E-000 RING SCREW 2 CTF-A12- 566-1
K87-M538C-000 POSITION PLATE 1 CTF-A32- 49-2
K87-M531D-000 SPRING 1 CTF-A32- 347
K87-M2316-000 THRUST WASHER 2 CTF- N2- 06
KW1-M4585-000 METAL 1 CTF-N32-
166-B1SPRING HOOK PIN 2 CTF- 42- 11-2
K87-M2382-000 CYL CONNECTOR 1 CTF- 53- 63-Y
K87-M1184-000 CONNECT PIN 1 CTF- 53- 64
K87-M2317-000 CAP 1 CTF- 54- 43
STUD 2 CTF- 54- 44
K87-M2387-000 PLANE WASHER 1 CTF- 54- 66-1
LEVER METAL 1 FTA-A24-1142
LEVER 1 FTA-A24-1145
KW1-M4584-000 ADJUST PLATE 1 FTA-A24-1148-B
SET PLATE 1 FTA-A24-1167
K87-M2381-000 AIR CYLINDER 1 PBSA 16_30-7
K87-M56C1-000 CONNECTOR 1 BF4BU
KW1-M4586-000 UNIVERSAL ELBOW 1 UEF
K87-M111S-000 SCREW,FLAT HEAD + 5 3MK-6-P
KW1-M45BG-000 SCREW,FLAT HEAD + 4 3MK-10-P
K87-M23B6-000 SCREW,FLAT HEAD + 2 4MK-8-P
K87-M11B9-000 CIRCLIP 1 E-24
KW1-M458F-000 DOUBLE RING 2
