1 KHY-M7106-A0 HEAD SHAFT 1 ASSY. 5
2 KHY-M7106-00 BALL SPLINE 1 5
3 KHY-M7107-A0 HEAD SHAFT 2 ASSY. 5
3-1 KHY-M7106-B0 HEAD SHAFT 1B ASSY. 5 (2009/1/14) MF10029 OK
4 KHY-M7107-00 BALL SPLINE 2 5
4-1 KHY-M7106-00 BALL SPLINE 1 5 (2009/1/14) MF10029 OK
5 KHY-M7105-00 HOLDER,NOZZLE 10
6 KHY-M7108-00 COLLAR,BRG. 10
7 KHY-M7111-00 HOLDER,BEARING 10
8 KHY-M7112-00 PLATE 1,BRG. 10
9 KHY-M7115-00 BRACKET,JOINT 10
9-1 KHY-M7115-01 BRACKET,JOINT 10 (2010/1/20) MG10062 OK
10 KHY-M7116-00 SPRING,RETURN 10
11 KHY-M711A-00 PIN,POST 10
11-1 Delete (2010/1/20) MG10062 OK
12 KHY-M7121-00 PULLEY,SHAFT 10
13 KHY-M7122-00 NUT,SHAFT 10
14 KHY-M7123-00 COLLAR,SHAFT 10
15 KG7-M7137-A0 LEAF SPRING 20
16 90990-02J005 SET SCREW M3X2 20
17 90990-08J016 SCREW,PAN HEAD 40
18 90990-15J003 NUT,HEXAGON 10
19 90990-17J053 O-RING 20
20 90990-22J009 PACKING 10
21 90933-02J104 BEARING 10
22 $TSH4-M5M JOINT 10
23 $PF-M3 PLUG 10
